XPON ONT P4（1GE+CATV）

P4 supports maximum data rates of up to 2.488Gbps downstream and 1.244Gbps upstream. Along with a 10/100/1000Mbps ...

Current position：HOME > PON

XPON ONT P4（1GE+CATV）

Overview        P4 supports maximum data rates of up to 2.488Gbps downstream and 1.244Gbps upstream. Along with a 10/100/1000Mbps, providing users with good QOS guarantee and flexible bandwidth allocation. Ethernet business and IP integrated services. Integrated CATV function, providing users with more efficient data transmission guarantee.
       P4 has high reliability and provides quality of service guarantee, easy management, flexible expansion and networking. It’s fully meet the ITU-T G984.x and IEEE802.3ah technical standards and has good compatibility with third party manufacturers OLT. Features         ● Dual mode (Can access EPON/GPON OLTs).
        ● Plug and play, integrate auto detection, auto configuration and auto firmware upgrading.
        ● Support downstream 2.5Gbps and upstream to 1.25Gbps with transmission distance to 20Km(GPON mode).
        ● Fiber access and gigabit port provide incredibly fast transfer speeds..
        ● Supports OMCI (ONT Management Control Interface) and OAM remote management.
        ● Support IPv4/ IPv6 IGMP snooping and MLD snooping. Technical Specifications

General

Protocol Standards

ITU-T G.984.x and IEEE802.3ah

Distance

20Km Max

Data Rates

GPON:Upstream rate 1.244Gbps

Downstream rate 2.488Gbps

EPON:Upstream rate 1.25Gbps

Downstream rate 1.25Gbps

PON TX Power

1~5dBm（1310nm）

PON RX sensitivity

<-28dBm（1490nm）

Power

≤ 4W

CATV

Optical Receive

-15～+2 dBm

AGC range

-12～-2 dBm

Fiber return loss

>14 dB

wave length

1100～1600 nm

Connector

RF

C/N

≥ 45 dB

C/CTB

≥ 62 dB

C/CSO

≥ 61 dB

BW

40~ 1000 MHz

Output level

≤82dBμV

Hardware

Interfaces

1xSC/UPC or 1xSC/APC (optional)

1x 10/100/1000Mbps LAN port

1x RF port

Buttons

Reset Button

Power Supply

DC 12V 0.5A

Dimensions (W x D x H)

104*73*22mm(length*width*height)

Environment

Operating Temperature

-10°C~50°C

Storage Temperature

-40°C~70°C

Operating Humidity

10%~90%, non-condensing

Storage Humidity

5%~95% non-condensing

Certifications

CE, RoHS

Software

WAN Type

Dynamic IP/Static IP/PPPoE

DHCP

Server, Client, DHCP Client List, Address Reservation

Quality of Service

Bandwidth Control

VLAN

Port-based VLAN

GVRP

IEEE802.1Q VLAN

Access Control

Local Management Control, Host List, Access Schedule, Rule Management

Route

Support NAT

Support PPPOE

Support Server Client

Support Route

PON Mode

GPON Mode

Management

Access Control

Local Management

Remote Management

Internet Protocol

IPv4, IPv6

Package Contents

Package Contents

1 x GPON ONT

1 x Quick Installation Guide

1 x Power Adapter
